Description
Surface-mounted push pad emergency exit device with vertical top-and-bottom bolts. Designed for emergency exit applications, it combines ease of use with high security and fire-door compatibility for commercial and institutional buildings.
Key features and benefits
- Surface-mounted push pad for quick, intuitive egress
- Vertical top and bottom shoots for secure two-point locking
- Anti‑thrust latches to prevent forced latch retraction and resist tampering
- Suitable for single doors, non‑rebated double doors, and for rebated double doors when used with Briton 378DDS double door strike and Briton 1438 emergency latch on the inactive leaf
- Fire & smoke door compatible: for doors up to 1300 mm wide, heights to 2500 mm, and door weights up to 200 kg
- Site reversible for easy left/right handing on site
- Adjustable top and bottom shoots for accurate fitting to door height
- Durable: cycle tested to over 200,000 operations
- Supplied with fixings and signage where applicable
- Backed by a 5‑year guarantee
Standards, approvals & performance
- UKCA marked to EN 179 (1121‑CPR‑ABB7573)
- CE marked to EN 179 (2812‑CPR‑ABB0020)
- Certifire approved (CF5506)
- Fire tested to EN 1634‑1 — 2‑hour timber door rating (1‑hour when used with an Outside Access Device); 4‑hour metal door rating
- Environmental Product Declaration compliant with ISO 14025 and EN 15804
